1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging

Name: 1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging
Brand: Linke
Price: 1 USD

Wholesale 1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging from china suppliers

Place of Origin : Guangdong, China

Brand Name : Linke

Certification : UL;ISO9001;ISO13485;IATF16949;TPU

MOQ : 1000m

Price : Negotiable

Packaging Details : According to requirement

Delivery Time : 7-15 days

Payment Terms : Advance 30% deposit and ship after receiving 70% final payment

Supply Ability : 100000000

Model NO. : LK-EV12

AMP : 1200A

Color : Customized

Customized : Customized

Plug Type : IEC 62196-2 (Type 2), SAE J1772 Type 1

Conductor : Bare Copper

Structure : 3034/0.20

Jacket : Silicone

Use : Charging

Transport Package : Roll

Specification : 95MM2

Trademark : LINKE

Origin : China

HS Code : 94054090

Package Size : 60.00cm * 55.00cm * 50.00cm

Package Gross Weight : 118.000kg

After-sales Service : 1year

Warranty : 1year

Samples : US$ 1000/PCS 1 PCS(Min.Order) |

Customization : Available

Shipping Cost : about shipping cost and estimated delivery time.

: Initial Payment Full Payment

Currency : US$

Return&refunds : You can apply for a refund up to 30 days after receipt of the products.

conductor material : copper/Tinned Copper

Conductor Type : Twisted wire

Exterior material : customize：PVC、PE、LSFOH、silicone rubber

insulating materials : customize:PVC、PE 、XLPE、EPR、SIR

specifications : 0.1-450mm²

rated voltage : 300-600V

rated temperature : -60± 200℃

colour : customize

type : insulated

package : By roll

Core : Multiple

Lead Time : 7-15days

Contact Now

OEM ODM Power Engine Wiring Harness for Automotive Vehicles

Product Specifications

Specification	Cable Name	EV Cable
Cable Spec	2C×80mm²+1C×25mm²+2C×4mm²+(3C×0.75mm²)(P2)+(7C×0.75mm²)
RoHS Compliant	Yes

Cable Components

Item	Description
A	2C×80mm²
B	1C×25mm²
C	1C×4mm²
D	(3C×0.75mm²)(P2)
E	(7C×0.75mm²)

Conductor Specifications

Component	Material	Size	O.D. (Ref.)
A	Bared copper stranded	2580/0.20 ±0.008mm	12.40±0.25mm
B	Bared copper stranded	798/0.20 ±0.008mm	7.00±0.20mm
C	Bared copper stranded	224/0.15±0.008mm +10/1#Tinsel+1000D Kevlar	2.70±0.15mm
D	Bared copper stranded	40/0.15±0.008mm+10/0.19mmTinsel+200DKevlar	1.40±0.10mm
E	Bared copper stranded	40/0.15±0.008mm+10/0.19mmTinsel+200D Kevlar	1.40±0.10mm

Insulation Properties

Parameter	Material	Min. Average Thickness	Min. Thickness at Any Point	O.D.
All Components	Thermoplastic (EF2585,85±3A)	1.60mm - 0.50mm	1.34mm - 0.35mm	15.60±0.40mm - 2.50±0.10mm

Electrical Characteristics

Parameter	Value
Rated Voltage	DC 1000V
Rated Temperature	Jacket: -40~90ºC, Insulation: -40~125ºC
Max. Conductor Resistance (20ºC)	A: 0.242Ω/km, B: 0.78Ω/km, C: 4.95Ω/km, D&E: 26Ω/km
Insulation Voltage Withstand	AC 2.5kV/5min, leakage current ≤5mA
Completed Cable Voltage Withstand	AC 3.5kV/15min, leakage current ≤5mA
Min. Insulation Resistance (20ºC)	500MΩ.km

Physical Properties

Property	Value
Tensile Strength	≥20MPa
Elongation	≥300%
Min. Bend Radius	6×OD
Abrasion Resistance	≥2000 times

Cable Structure Reference

Type	Conductor mm²	Structure	Conductor Material	Insulation Material	Insulation OD (mm)	20ºC Conductor Resistance (Ω/KM)
EV-YJ	1.5	48/0.20	Copper	Silicone	2.90±0.15	≤12.7
EV-YJ	2.5	80/0.20	Copper	Silicone	3.50±0.15	≤7.60
EV-YJ	4	128/0.20	Copper	Silicone	4.30±0.15	≤4.71
EV-YJ	6	196/0.20	Copper	Silicone	5.10±0.20	≤3.14
EV-YJ	10	322/0.20	Copper	Silicone	6.70±0.20	≤1.82

1200A Customized Silicone Jacket EV Charger Cable for Electric Vehicle Charging

Key Features

Conductor: Flexible bare annealed copper wire
Insulation: High-quality silicone
Color options: Black, Orange, Red, Yellow, Blue jacket
Single & double insulated options available
SQ MM sizes (European style): 4 sq mm to 240 sq mm
AWG sizes (North American style): 0AWG-10AWG
Wide temperature range: -60°C to 200°C
Low viscosity appearance for easy installation

Quality Certifications

SO9001 and ISO13485, TS16949

CNR - Appliance Wiring Material

Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2

Extruded PVC Non-integral Jacketed Cable, rated 105ºC, 1000V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2

Extruded TPU Non-integral Jacketed Cable, rated 80ºC, 300V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2

Frequently Asked Questions

Are you a manufacturer or trading company?

We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.

How can I get a sample to test your quality?

The samples are free for you. New clients are expected to pay for the courier cost.

What's your Minimum Order Quantity?

Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.

Can I get a discount?

It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.

Does your company accept OEM production?

Yes, we can print your company name, and we even customize the quality card to promote your company.
